ADJ Ultra LB18 LED Bar 18 x 10W Strobe light

ADJ Ultra LB18 LED Bar 18 x 10W Strobe light

Key Features

  • • Linear Color Temperature Control (2,300K to 9,900K)
  • • Smooth RGBAL color mixing
  • • Horizontal Magnetic Alignment feature (Built-In)
  • • Compatible with the ADJ UC IR remote. Operates at a distance of up to 32.8 feet (10 meters)
  • • Glare shield that blocks the LEDs from glare/view and protects LEDs during transport
  • • USB Service Por
  • • Digital Display with 4-button menu
  • • 11 DMX Channel Modes: 5, 8, 10, 13, 16, 30, 33, 38, 41, 60 & 71 Channels
  • • 6 Groups x3 RGBAL LED pixels controllable via DMX in 30, 33, 38, 41, 60 & 71 channel modes
  • • 6 operational modes: Auto Run, Program Mode, Sound Trigger, RGBAL Manual, Static Color and DMX-512 Mode
  • • Flicker Free operation (No flickering on camera)
  • • Selectable refresh rates from 2.88KHz to 25kHz
  • • 64 built-in Color Macros, including 15 white color temperature presets
  • • 6 selectable Dim Modes (Standard, Stage, TV, Architectural, Theatre & Stage 2)
  • • 4 selectable Dim Curves (Square, Linear, Inv. Square & S. Curve)
  • • Built-In Microphone for sound trigger mode
  • • LED pulse and strobe effect
  • • Electronic Dimming: 0-100

Product Overview

The ADJ Ultra LB18 is a professional LED wash batten featuring 18 × 10 W RGBLC LEDs (Red, Green, Blue, Lime, Cyan) capable of generating smooth, high-output colour mixing and wide wash coverage. The fixture offers variable intensity and colour control, strobe effects, and built-in macro looks, with control via DMX512, master/slave, or standalone modes. The batten’s linear design produces even illumination across its length, making it suitable for wall washes, stage backlighting, and architectural uplighting.

Constructed with a rigid metal housing and equipped with adjustable mounting brackets, the unit supports secure truss or floor placement. Power and data are delivered through industry-standard powerCON and 3-pin/5-pin DMX connectors, enabling seamless integration into lighting rigs. Integrated thermal management and efficient LED drivers ensure stable performance in professional event environments.

Specifications

Condition
New
• Linkable
DMX via 5-pin XLR cable
Electrical
• Multi-voltage operation
AC 100V-240V 50/60Hz
• Power Draw
130W
Dimensions / Weight
• Dimensions (LxWxH)
3.39" x 39.3" x 7.42" (86x996x188.4mm)
• Weight
12.13 lbs./ 5.5kg.
